DYNA 52 럭셔리 파워요트 소개(홍보)

DYNA 52 POWER YACHT





안녕하세요.



요트보트코리아에서는 DYNA YACHT 52피트급



대형 럭셔리 파워요트를 소개합니다.



https://www.youtube.com/watch?v=2wovdyfarts&t=1s



GENERAL SPECIFICATION

1. LENGTH OVERALL（INCLUDE PULPIT AND FIXED PLATFORM) : 16.24M(53’-4”)

2. BEAM MAX : 4.52M (14’-10”)

3. DRAFT UNDER PROPELLERS : 1.22M (4’)

4. HEIGHT ABOVE WATER LINE TO TOP OF MAST : 6.4M (21’)

5. APPROX. DISPLACEMENT : 17,500KGS (38580LBS)

6. FUEL CAPACITY : 1,892L (500 US GALS)

7. FRESH WATER CAPACITY : 454L (120 US GALS)

8. SLEEPING ACCOMODATION : 6 ~ 10P

9. TWIN VOLVO PENTA IPS 700 DIESEL ENGINES WITH SUITABLE GEARS

10. onAN GENERATOR 17KW/60HZ (13.5KW/50HZ)

11. MARINE AIR AIRCONDITIONER W/REVERSE CYCLE HOT & COLD TOTAL 34,000BTUs



HULL FORM AND CONSTRUCTION



1. DEEP V HULL BOTTOM

2. ALL FIBERGLASS THROUGHOUT THE BOAT IS LAID UP BY VACUUM INFUSION

3. FOAM CORE CONSTRUCTION ABOVE WATER LINE

4. SOLID FIBERGLASS CONSTRUCTION BELOW WATER LINE

5. EXTENSIVE NETWORK OF TRANSVERSE AND LONGITUDINAL STRINGERS GLASSED IN THE HULL BOTTOM

6. INTERIOR OF HULL BOTTOM PAINTED OUT IN WHITE PU PAINT

7. DECK SIDES ARE FOAM CORE CONSTRUCTION

8. CABIN TOPS ARE BALSA CORE CONSTRUCTION

9. HULL AND DECK ARE BOLTED AND FRP BONDED TOGETHER

10. MOULDED NON-SLIP DECK SURFACE

11.  ANTIFOULING

12. LAMINATION WITH VINYLESTER RESIN on TWO LAYERS OF SURFACE



DECK FITTING



1. REVERSIBLE ELECTRIC LOFRANS WINDLASS WITH REMOTE CONTROL FROM BOTH HELM AND DIRECT CONTROL on THE FORE DECK

2. STAINLESS STEEL ANCHOR 45LBS & GALVANIZED CHAIN 50M

3. FLAG POLE SOCKET

4. STAINLESS STEEL BOW ROLLER AND CHAINWAY

5. CHAIN LOCKER W/HATCH

6. STAINLESS STEEL PULPIT & HAND RAIL

7. STAINLESS STEEL TWIN BOW, SPRING AND STERN CLEATS

8. STAINLESS STEEL OPENING PORTHOLES WITH SCREENS

9. HEAVY DUTY RUBBER WITH STAINLESS STEEL RUBRAIL

10. WINDOWS IN TEMPERED GLASS DIRECTLY MOUNTED on FRP 11. FORE DECK ROUND ESCAPE HATCH

12. FWD DECK SUN LOUNGE PAD

13. WATER AND FUEL FILLERS

14. FENDER RACKS

15. SELF DRAINING



COCKPIT



1. STAINLESS STEEL FRAME SLIDING DOOR TO SALOON

2. FRP STAIRS TO FLYBRIDGE WITH STORAGE UNDERNEATH

3. TEAK LAID on SWIMMING PLATFORM AND COCKPIT

4. COCKPIT FRP SEAT WITH CUSHION AND STORAGE UNDERNEATH

5. SHORE POWER INLET

6. AFT DECK WASH DOWN(FRESH WATER)

7. COCKPIT LED LIGHTING

8. WATERPROOF STEREO SPEAKERS

9. TRANSOM DOOR TO SWIMMING PLATFORM

10. TRANSOM SHOWER HOT AND COLD

11. STEPS TO SIDE DECKS

12. SWIMMING PLATFORM AND CONCEALED STAINLESS STEEL LADDER

13. ACCESS DOOR FROM LAZARETTE TO ENGINE ROOM

14. MANUAL BILGE PUMP WITH CHEST VALVE IN LOCKER

15. COCKPIT HATCH TO LAZARETTE WITH S/S LADDER

16. SELF DRAINING

17. TRIM TABS W/ INDICATORS



FLYBRIDGE AND SECOND HELM STATION



1. STAINLESS STEEL HANDRAILS WITH ACRYLIC WINDSHIELD

2. FLYBRIDGE FRP INSTRUMENTS BOARD WITH ACRYLIC COVER 3. HYDRAULIC STEERING SYSTEM WITH STEERING WHEEL

4. ELECTRONIC ENGINE CONTROLS

5. START/STOP BUTTONS AND ENGINES KEYS

6. ENGINE RPM GAUGES

7. ENGINE COOLING WATER TEMPERATURE GAUGES

8. ENGINE OIL PRESSURE GAUGES

9. AUDIBLE AND VISUAL ENGINE ALARM

10. BILGE PUMP AUDIBLE ALARM

11. REMOTE WINDLASS CONTROL

12. SEARCH LIGHT WITH REMOTE CONTROL

13. COMPASS AND MARINE HORN

14. RUDDER AND TRIM TAB INDICATORS

15. INTERCOM SYSTEM

16. FRP HELM SEAT WITH CUSHION

17. WET BAR W/ CABINET FOR ICE MAKER AND BBQ OR STORAGE (NOTE: ICE MAKER AND BBQ ARE OPTIONAL)

18. FRP SETTEE WITH CUSHION AND TABLE

19. SUN LOUNGE PAD

20. ACCESS HATCH FROM COCKPIT BY FRP STAIRSWAY

21. RADAR ARCH

22. INTERNATIONAL NAVIGATION LIGHTS

23. WATERPROOF STEREO SPEAKERS

24. FLAG POLE SOCKET

25. FRP NONSKID FLOOR

26. SELF DRAINING



LOWER MAIN HELM STATION



1. LEATHER HELM SEAT

2. NAVIGATION PANEL

3. ELECTRONIC ENGINE CONTROLS & INSTRUMENTS

4. HYDRAULIC STEERING SYSTEM & STEERING WHEEL

5. WINDLASS CONTROL

6. SEARCHLIGHT CONTROL

7. FUEL GAUGE

8. RUDDER AND TRIM TAB INDICATORS

9. COMPASS AND MARINE HORN SWITCHES

10. INTERCOM

11. ENGINE ROOM EXTINGUISHING AND AUTOMATIC SHUT DOWN SYSTEM

12. WINDSCREEN WIPERS WITH FRESH WATER WASH SYSTEM

13. DC & AC CONTROL PANELS



INTERIOR



1. PLYWOOD CABIN SOLE THROUGHOUT WITH CARPET（EXCEPT GALLEY）

2. CHOICE OF WOOD VENEER on SIDES AND COUNTER TOP (STANDARD SELECTIONS INCLUDE TEAK, MAPLE, CHERRY, WALNUT AND OAK.)

3. CHOICE OF UPHOLSTERY FABRICS FOR CURTAINS AND BED MATTRESS COVERS (OPTIONAL PILLOWS AND BEDSPREADS FOR CABINS)

4. VINYL HEAD LINERS

5. CHOICE OF LEATHER SEATINGS

6. WOODWORK IN SATIN OR GLOSSY FINISH

7. STANDARD THREE CABINS WITH GALLEY + DINETTE AFT LAYOUT

8. LED CEILING LIGHTS THROUGHOUT

9. VIMAR SWITCHES AND OUTLETS

10. GROHE SHOWER FITTINGS

11. GFI OUTLETS IN CABIN HEADS AND GALLEY AREA



LOWER SALOON

1. FRIDGE AND FREEZER

2. SINKS WITH HOT AND COLD MIXER FAUCET AND CHOPPING BOARD COVER

3. ELECTRIC COOKTOP

4. MICROWAVE OVEN

5. EXTRACTOR FAN ABOVE COOKTOP

6. TRASH BIN

7. EYE LEVEL CABINET & DISH LOCKER

8. DRAWERS AND STORAGE

9. CORIAN COUNTERTOP

10. BAR WITH ICE MAKER AND LIQUOR CABINET

11. TEAK FLOORING

12. STAINLESS STEEL FRAMED SILDING DOOR TO COCKPIT

13. SWITCHES, POWER SOCKETS & AIR CONDITIONG CONTROL



UPPER SALOON



1. L-SHAPE LEATHER SETTEE AND TABLE

2. LEATHER BENCH SEAT

3. ENTERTAINMENT CABINET WITH TV PRE-WIRING

4. BLUETOOTH CD PLAYER WITH 2 SPEAKERS AND VOLUME CONTROLS

5. CONCEALED TUBE LIGHTS UNDER CURTAIN BALANCE

6. LED CELING LIGHTS

7. CARPET FLOORING

8. SWITCHES AND POWER SOCKETS

9. CONCEALED ELECTRICAL PANELS WITH MAIN SWITCHES AND AC/DC BREAKERS

10. ACCESS STAIRS TO LOWER DECK WITH LIGHTS



FWD VIP CABIN



1. QUEEN SIZE BERTH WITH STORAGE UNDERNEATH

2. TWIN DRESSING TABLES AND DRAWERS

3. HANGING LOCKER WITH LIGHT

4. ESCAPE HATCH TO FOREDECK

5. LED CEILING LIGHTS & READING LIGHTS

6. SWITCHES & POWER SOCKETS

7. 2 SPEAKERS W/VOLUME CONTROL CONNECTED FROM SALOON DVD PLAYER

8. OPENING PORTHOLES

9. INTERCOM

10. AIRCONDITIONING CONTROL



FWD HEAD



1. CABINET AND MIRROR

2. ELECTRIC MARINE TOILET W/HOLDING TANK FOR SEA/DOCKSIDE DISCHARGE

3. WASH BASIN WITH HOT AND COLD WATER MIXER FAUCET

4. CORIAN COUNTERTOP

5. HOT AND COLD SHOWER WITH AUTOMATIC PUMP OUT

6. INDEPENDENT SHOWER ROOM WITH DOOR AND TEAK GRATE FLOOR

7. SHOWER AND FAUCET FITTINGS

8. TOWEL HOLDER

9. TOILET PAPER HOLDER

10. SOAP DISH

11. ROBE HOOK

12. CUP HOLDER

13. OPENING PORTHOLE

14. EXTRACTOR FAN



GUEST CABIN



1. 2 SINGLE BEDS

2. HANGING LOCKER W/ LIGHT

3. NIGHTSTAND W/ DRAWER UNDERNEATH

4. LED CEILING LIGHTS AND READING LIGHTS

5. SWITCHES & POWER SOCKETS

6. INTERCOM

7. OPENING PORTHOLE

8. STEREO SPEAKERS W/VOLUME CONTROL CONNECTED FROM SALOON DVD PLAYER

9. ACCESS DOOR



MID MASTER CABIN



1. KING SIZE BERTH WITH STORAGE UNDERNEATH

2. HANGING LOCKER W/LIGHT

3. NIGHTSTANDS W/DRAWERS UNDERNEATH

4. CEILING AND READING LIGHTS

5. SWITCHES AND POWER SOCKETS

6. CONCEALED TUBE LIGHTS UNDER CURTAIN BALANCE

7. INTERCOM

8. STEREO SPEAKERS WITH VOLUME COTROLS CONNECTED FROM SALOON CD PLAYER

9. NON-OPENING VERTICAL PORTLIGHTS

10. PRIVATE ACCESS TO MASTER HEAD

11. TV PREWIRING



MASTER HEAD



1. CABINET AND MIRROR

2. ELECTRIC MARINE TOILET W/ HOLDING TANK FOR SEA/DOCKSIDE DISCHARGE

3. WASH BASIN WITH HOT AND COLD WATER MIXER FAUCET

4. GRANITE OR CORIAN COUNTERTOP

5. INDEPENDENT SHOWER ROOM WITH DOOR AND TEAK GRATE FLOOR

6. HOT AND COLD SHOWER W/ AUTOMATIC PUMP OUT

7. TOWEL HOLDER

8. TOILET PAPER HOLDER

9. SOAP DISH

10. ROBE HOOK

11. CUP HOLDER

12. OPENING PORTHOLE

13. EXTRACTOR FAN

14. ACCESS FROM MASTER CABIN



ENGINE ROOM COMPARTMENT & STERN GEARS



1. AIR INTAKES AND EXHAUST BLOWERS W/ TUBING

2. WATER COOLED ENGINE EXHAUST

3. FUEL/WATER FILTERS

4. LEAD FOAM ENGINE ROOM SOUND INSULATION

5. ENGINE ROOM DC LIGHTS

6. ALUMINIUM FUEL TANK W/ SEPARATE FILLERS AND VENTS

7. HIGH CAPACITY ELECTRICAL BILGE PUMPS W/ FLOAT SWITCHES

8. ENGINE ROOM FIRE EXTINGUISHING SYSTEM WITH AUTOMATIC ENGINE SHUT DOWN

9. SHAFTS WITH DRIPLESS SHAFT SEALS（EXCEPT IPS ENGINE） 10. 4 BLADE MN-BZ PROPELLERS（EXCEPT IPS ENGINE）

11. BRONZE STRUTS（EXCEPT IPS ENGINE）

12. STAINLESS STEEL RUDDERS WITH STAINLESS STEEL POSTS（EXCEPT IPS ENGINE）

13. FLEXIBLE ENGINE MOUNTINGS

14. AIR-CONDITIONING COMPRESSING UNITS

15. MAIN GENERATOR

16. ENGINE ROOM NONSKID FLOORING

17. COLOR CODED PLUMBING SYSTEM

18. FRESH WATERTANK

19. 12 GALS WATER HEATER

20. FRESH WATER FAUCET

21. GFI OUTLETS IN ENGINE ROOM

22. ACCESS FROM THE COCKPIT



MECHANICAL & MISCELLANOUS



1. STAINLESS STEEL WATER TANK W/FILLER AND SHORE WATER CONNECTION

2. WATER LEVER GAUGE

3. 12 GALS WATER HEATER CONNECTED TO GENERATOR COOLING SYSTEM

4. AUTOMATIC WATER PRESSURE PUMP FOR HOT AND COLD WATER

5. GREY WATER TANK W/PUMP

6. HOLDING TANK W/MACERATOR PUMP AND SEA/DOCKSIDE DISCHARGE

7. HOLDING TANK LEVER GAUGE

8. MANUAL BILGE PUMP

9. SEA WATER STRAINERS

10. ALL THRU-HULL WITH SEACOCKS
11. SEA WATER PUMP W/DECK WASH DOWN IN CHAIN LOKER

12. AFT DECK WASH DOWN（FRESH WATER）



ELECTRICAL APPLIANCES



1. ALL DC&AC CIRCUITS PROTECTED BY CIRCUIT BREAKERS

2. COLOR CODED WIRING SYSTEMS

3. BATTERY MASTER SWITCH AT MAIN SWITCH PANEL

4. BONDING SYSTEM W/ZINC PLATES



(A) 12V SYSTEM



1. 12V FOR NAVIGATING AND RADIO CIRCUITS

2. onE 100 A.H. BATTERY FOR GENERATOR START AND CHARGED BY GENERATOR OR BATTERY CHARGER

3. DC 12V BATTERY CHARGER



(B) 24V SYSTEM



1. onE 200 AH BATTERIES FOR THE DOMESTIC SERVICE AND ACCEPT CHARGE FROM BATTERY CHARGER OR ENGINE

2. onE 200 AH BATTERIES START BOTH ENGINE AND CHARGED BY ENGINE OR BATTERY CHARGER

3. DC LIGHTING THROUGHOUT



(C) 120V SYSTEM (240V AVAILABLE)



1. SHORE POWER SUPPLY

2. GENERATOR/SHORE SUPPLY CHANGE OVER SWITCHS

3. POLARITY CHECK LIGHT

4. AC SOCKETS THROUGHOUT

5. SPARE CIRCUIT BREAKERS ARE PROVIDED FOR OPTIONAL EQUIPMENT

6. AC INSERT TUBE LIGHTS

7. EARTH LEAKAGE SAFTY TRIP

8. COLOR CODED WIRING SYSTEM





DYNA 52 추가옵션 리스트





DYNA 52 POWER YACHT 국내판매가격



기본옵션 사양 판매가격 : 15억 5,000만원

(부가세별도/국내세팅 및 인도/선박안전검사비포함)

엔진 : TWIN VOLVO PENTA IPS 700 DIESEL ENGINES



​



DYNA 52 파워요트 계약은 ?

☞☞ 계약금은 전체 계약금액의 20%

☞☞ 1차송금(송금후 건조시작)은 전체 계약금액의 30%

 ☞☞ 2차송금(6개월후 본사 출발전)은 전체 계약금액의 30%

☞☞  잔금(부산도착 통관후 인수시)은 ​전체 계약금액의 20%



요트보트코리아에서는 계약한 보트금액에 대한



고객의 안전 보장을 위하여 보증보험사에서



안전하게 100% 보장해 드립니다.









24시간 카톡상담 ID : hobiekorea





상담 연락처 : 010-9699-2063



























































요트보트코리아 로고를 클릭하시면 새로운 커뮤니티가...???
